An automatic tool changer, or ATC, is the tool package in machining and manufacturing procedures, which allows a CNC (computer numerical control) machine or robot to change tools without human involvement. ATC systems automate the workflow, increasing efficiency and reducing downtime. They assure high precision because of the fast and accurate tool changes made for various operations such as milling, drilling, or cutting. The ATC kits come in useful where there are operations that need a number of tools for one production run, yielding higher productivity and flexibility in the automated CNC system.

ATC CNC Routers: Applications and Industry Benefits

ATC CNC router gives the industry maximum efficiency and versatility. It comes with an automatic tool-changing feature, mainly adopted by woodworking, sign-making, and fabrication. This feature greatly reduces manual intervention, hence increasing productivity. Users will love the precision and ability to easily handle complex designs through advanced software integration and solid construction. With its powerful ATC spindle, large working table, and super-friendly interface, this is the ideal CNC for either a hobby or professional setup.

Benefits of Upgrading CNC Routers with ATC Kits

Upgrading your ordinary CNC router with automatic tool changer kits can change not only the performance and precision but also the efficiency of the machine. Such advanced features include higher spindle speeds, better motion control, and upgraded software in the CNC controller, allowing much more intricate designs to be made with much less processing time. Furthermore, the high-end ATC kits usually have user-friendly interfaces, improved safety features, and compatibility with a wide range of materials, thus rendering them quite versatile in nature for different projects. The upgraded ATC CNC machine can eventually bring better returns on investment and keep your CNC machining operation competitive against a quickly changing landscape.

Here is one of STYLECNC’s popular ATC CNC woodworking router machines with a linear automatic tool changer for every need – STM1325CH. Let’s start to review this machine in detail.

Features of 4×8 CNC Wood Router with Linear Automatic Tool Changer

• Thick steel welded structure, stable at high temperature, small deformation, good rigidity and high strength.

• Stronger AC servo motor allows the machine to run smoothly, with low noise, high speed, and high precision.

• 9KW air-cooling spindle, high precision, long service life, and smooth movement.

• High-quality 12 tool magazine, high speed tool change within 8 seconds.

• Tool sensor allows the machine to compensate for tool length errors.

• Top brand Taiwan LNC control system, independent keyboard control, color LCD display, making the machine more versatile.

• Powerful dust collector to ensure site cleanliness during machine operation.

• Automatic lubrication system, one-click easy regular maintenance.

Technical Parameters of 4×8 Linear ATC CNC Wood Router Machine 1325

50m/min

ModelSTM1325CH
Table Size4′ x 8′
Working Area1300x2500x300mm
Resolution0.01mm
Lathe StructureSeamless welded steel structure, superior to cast iron structure
X/Y Axis StructureTaiwan Hiwin H30 square guide rail for gear transmission, rack and pinion
Z-Axis StructureTaiwan TBI ball screw, Taiwan Hiwin H30 square guide rails
Max. Idling Speed50m/min
Spindle9.0KW air-cooling ATC spindle+3.5KW horizontal spindle
Spindle Speed0-24000r/min, variable speed
Working VoltageAC380V/3P/50HZ or 220V/2P/3P/60HZ
Motor and Driver1500W Leadshine servo motor
Working ModeServo
CommandG code (HPGL, U00, mmg, plt)
CNC System & SoftwareTaiwan LNC CNC controller
Tool Diameterφ3.175 – φ12.7
Cooling SystemAir cooling
Dust CollectorYes
WorkholdingSuction or clamp
Tool MagazineLinear type automatic tool changer kit with 12 router bits
Net Weight2300KG

Main Parts of 4×8 Woodworking CNC Router Table 1325 with Linear Automatic Tool Changer
